| Brand Name : | SevenPower |
| Certification : | CE |
| Delivery Time : | 25days |
| Model Number : | SP100N |
| Price : | Negotiable |
| Payment Terms : | L/C, T/T |
Continuous 100KW Natural Gas CHP , Synchro CHP Cogeneration Systems
Super Silent Running
Production Service
-Keep customers posted on the progress of production.
-Systematical and strict shop testing before delivering to
customers
-Testing
Natural gas CHP SP100N/24hours Continuous Electrical Output 100kw
-Powered by converted CUMMINS engine
-6cylinders water-cooled type internal combustion engine
-RPM1500,longer service life
-Recover heat from engine body and exhaust manifold and exhaust
-Integrated control cabinet
-Safe gas train
-Advanced gas engine control system, ignition system, speed control system, air/fuel ratio control system
-All necessary engine protections, oil pressure, water temperature, over current, over voltage, overload, engine speed, frequency protection, battery voltage
-Easy control system, all information easily read from the controller screen, power output,voltage,current,power factor, engine speed,oil pressure,coolant temperature,battery voltage,run hours,start numbers,alarms,historical records
Main Characters
| Model | SP110N | |
| fuel | — | Natural Gas |
| marks | — | Synchro CHP |
| electrical output(KWe) | kVA/kWe | Continuous Power |
| 125/100 | ||
| thermal output(KWe) | kWt | 171 |
| electrical efficiency | % | 30.8% |
| thermal efficiency | % | 52.7% |
| overall efficiency | % | 83.5% |
| frequency | Hz | 50 |
| voltage | V | 400/230 |
| gas inlet pressure | kPa | 3-5 |
| dimension (soundproof type) | mm*mm*mm | 2600*1550*1650 |
| net weight | kg | 2700 |
| NG consumption | m3/kW.h | 0.296 |
| db(A)@7m | — | 58 |
| Certificate | — | CE |
| water-water heat exchanger | — | SWEP |
| water-exhaust heat exchanger | — | designed by our own factory/made of full stainless steel |
| ignition system | — | Impco |
| speed governor | — | Woodward |
| mixer | — | Venturi type |
| gas filter | — | Madas |
| zero regulator | — | Kromschroeder |
| solenoid valve | — | Kromschroeder |
| gas pressure gauge | — | Dungs |
| Lambda auto control | — | Available on request with extral cost |
| catalyst converter | — | Available on request with extral cost |
| MCB | — | ABB |
| GCB | — | ABB |
| Controller | ComAp | |
| Engine model | — | SP-6CTA |
| Engine type | — | 6 cylinders,4stroke,water-coolled |
| RPM | — | 1500 |
| Compression Ratio | — | 10.5 |
| Displacement | — | 8.3L |
| Oil capacity | — | 19L |
| Charging voltage | — | 24V(DC) |
| Charging current | — | 5A(DC) |
| Starting system | — | Electic-start |
| Alternator model | — | Meccalte |
| phase | — | 3 phase 4 wires |
| insulation system | — | class H |
| protection | — | IP23 |
| Cooling Type | — | air cooled |
Optional at
3 Different Applications
Picture for reference
SevenPower 100KW Natural Gas CHP On Site Picture(Europe)
For more information about each CHP, please consult with your sales
representative.Thanks.
