| Brand Name : | SevenPower |
| Model Number : | SP8N |
| Certification : | CE |
| Delivery Time : | 25days |
| Price : | Negotiable |
| Payment Terms : | L/C, T/T |
3P3W Asynchro 8KW 10KVA CHP With Water Cooled Alternator Grid-on Cogeneration 60HZ Single Phase 10KW CHP 10KW COGEN
Recover heat from 4 sources
- Engine jacket water
- Alternator cooling water
- Exhaust
- Exhaust manifold
Main Specifications
| Model | SP9N | |
| fuel | — | Natural Gas |
| marks | — | A-synchro CHP |
| electrical output(KWe) | kVA/kWe | Continuous Power |
| 10/8 | ||
| thermal output(KWt) | kWt | 20.4 |
| electrical efficiency | % | 25.6% |
| thermal efficiency | % | 65.3% |
| overall efficiency | % | 90.9% |
| frequency | Hz | 50 |
| voltage | V | 400/230 |
| gas inlet pressure | kPa | 1-10 |
| Water Flow | m³/h | 2 |
| dimension (soundproof type) | mm*mm*mm | 1530*750*940 |
| net weight | kgs | 550 |
| NG consumption | m3/kW.h | 0.396 |
| Certificate | — | CE |
| water-water heat exchanger | — | SWEP |
| water-exhaust heat exchanger | — | designed by our own factory/made of full stainless steel |
| ignition system | — | Impco |
| speed governor | — | Woodward |
| gas filter | — | Madas |
| zero regulator | — | Maxitrol |
| pressure gauge | — | DUNGS |
| soft start | — | ABB |
| switch | — | ABB |
| lambda control | — | Available on request |
| catalyst converter | — | Available on request |
| ComAp | ||
| Engine model | — | SP9EW |
| Engine type | — | 4 cylinders,4stroke,16valves,water-coolled |
| RPM | — | 1500 |
| Compression Ratio | — | 11 |
| Displacement | — | 1.5L |
| Oil capacity | — | 3.9L |
| Charging voltage | — | 12V(DC) |
| Charging current | — | 6A(DC) |
| Starting system | — | Electic-start |
| model | — | SP9AW |
| phase | — | 3 phase |
| insulation system | — | class H |
| protection | — | IP65 |
| Cooling Type | — | water cooled |
| max return temp | ℃ | 70 |
Asynchronous 8kw CHP on Site Picture
For more specifications about the CHP, please consult with your sales representative.Thanks.
|
|
